Unitract™ Series Low Pressure reels are ideally suited for plant maintenance or many other industrial functions where hose storage is a problem. Standard hose for air, water and oxygen/acetylene applications. Hose can be dispensed and retracted with greater ease and expedience than coiling by hand. The Unitract™ series fits easily into height restricted areas, and is a lighter duty reel. Designed for stationary applications; do not use on mobile applications.
Standard: Carbon Steel zinc coated
MODEL # | WEIGHT | PSI | HOSE CAPACITY ID | HOSE CAPACITY FT | REEL INLET | REEL OUTLET |
---|---|---|---|---|---|---|
|
36 | 1000 | 3/8" | 50' | 1/2" NPT (F) | 1/2" NPT (F) |
|
36 | 1000 | 1/2" | 50' | 1/2" NPT (F) | 1/2" NPT (F) |
MODEL # | WEIGHT | PSI | HOSE CAPACITY ID | HOSE CAPACITY FT | REEL INLET | REEL OUTLET |
---|---|---|---|---|---|---|
|
44 | 300 | 3/8" | 50' | 1/2” NPT (F) | 1/4” NPT (M)* |
|
47 | 300 | 1/2" | 50' | 1/2” NPT (F) | 1/4” NPT (M)* |
